średnica wału
|
Numer modelu
|
Wymiary ((mm)
|
|
|
Obciążenie podstawowe ((N)
|
|
|||
|
(mm)
|
Stary
|
Identyfikacja
|
Nadmiar
|
W
|
Dynamiczny
|
Statyczny
|
|||
|
|
|
Fw
|
D
|
B
|
|
|
|||
|
8
|
F-08410
|
8
|
14
|
10
|
5200
|
7150
|
|||
|
|
F-08412
|
8
|
14
|
12
|
4550
|
7150
|
|||
|
9
|
F-091510
|
9
|
15
|
10
|
8000
|
11500
|
|||
|
|
F-091513
|
9
|
15
|
13
|
8560
|
12800
|
|||
|
10
|
F-101615
|
10
|
16
|
15
|
6890
|
11500
|
|||
|
12
|
F-121712
|
12
|
17
|
12
|
8400
|
11900
|
|||
|
|
F-121715
|
12
|
17
|
15
|
9000
|
12500
|
|||
|
|
F-121718
|
12
|
17
|
18
|
9800
|
13500
|
|||
|
|
F-1212
|
12
|
18
|
12
|
6380
|
10900
|
|||
|
13
|
F-1312
|
13
|
19
|
12
|
8500
|
14200
|
|||
|
14
|
F-1412
|
14
|
20
|
12
|
7900
|
13500
|
|||
|
|
F-1416
|
14
|
20
|
16
|
12700
|
22400
|
|||
|
15
|
F-152012
|
15
|
20
|
12
|
8400
|
11900
|
|||
|
|
F-152016
|
15
|
20
|
16
|
9500
|
12800
|
|||
|
|
F-152020
|
15
|
20
|
20
|
10500
|
16000
|
|||
|
|
F-1512
|
15
|
21
|
12
|
9700
|
15900
|
|||
|
|
F-1516
|
15
|
21
|
16
|
9700
|
15500
|
|||
|
16
|
F-1616
|
16
|
22
|
16
|
14100
|
25900
|
|||
|
|
F-1612
|
16
|
22
|
12
|
8700
|
15500
|
|||
|
17
|
F-1712
|
17
|
23
|
12
|
10600
|
21600
|
|||
|
|
F-1714
|
17
|
23
|
14
|
12500
|
22500
|
|||
|
|
F-1716
|
17
|
23
|
16
|
13200
|
23700
|
|||
|
|
F-1718
|
17
|
23
|
18
|
13800
|
24800
|
|||
|
|
F-1720
|
17
|
23
|
20
|
18000
|
36700
|
|||
|
|
F-1722
|
17
|
23
|
22
|
19300
|
38200
|
|||
|
18
|
F-1812
|
18
|
24
|
12
|
10800
|
19200
|
|||
|
|
F-18916
|
18
|
24
|
16
|
15000
|
29100
|
|||
|
20
|
F-2010
|
20
|
26
|
10
|
8000
|
15600
|
|||
|
|
F-2012
|
20
|
26
|
12
|
10200
|
19500
|
|||
|
|
F-2014
|
20
|
26
|
14
|
15800
|
40500
|
|||
|
|
F-2016
|
20
|
26
|
16
|
16000
|
30500
|
|||
|
|
F-2020
|
20
|
26
|
20
|
18800
|
42500
|
|||
|
|
F-2025
|
20
|
26
|
25
|
20500
|
35500
|
|||
|
22
|
F-2210
|
22
|
28
|
10
|
7900
|
13000
|
|||
|
|
F-2212
|
22
|
28
|
12
|
9000
|
13300
|
|||
|
|
F-2216
|
22
|
28
|
16
|
17000
|
33000
|
|||
|
|
F-2220
|
22
|
258
|
20
|
20300
|
47200
|
|||
|
25
|
F-2512
|
25
|
32
|
12
|
5250
|
6000
|
|||
|
|
F-2516
|
25
|
32
|
16
|
18700
|
37900
|
|||
|
|
F-2520
|
25
|
32
|
20
|
22800
|
46000
|
|||
|
|
F-2522
|
25
|
32
|
22
|
11000
|
16500
|
|||
|
|
F-2525
|
25
|
32
|
25
|
11500
|
18500
|
|||
|
